Cortex-M4

The Arm Cortex-M4 processor is a highly-efficient embedded processor.

Block Diagram on Cortex-M4.

Getting Started

The Cortex-M4 processor is developed to address digital signal control markets that demand an efficient, easy-to-use blend of control and signal processing capabilities. The combination of high-efficiency signal processing functionality with the low-power, low cost and ease-of-use benefits of the Cortex-M family of processors satisfies many markets. These industries include motor control, automotive, power management, embedded audio and industrial automation markets.

Specifications

Architecture Armv7E-M
Bus Interface 3x AMBA AHB-Lite interface (Harvard bus architecture)
AMBA ATB interface for CoreSight debug components
ISA Support Thumb/Thumb-2
Pipeline 3-stage + branch speculation
DSP Extension
 Single cycle 16/32-bit MAC
Single cycle dual 16-bit MAC
8/16-bit SIMD arithmetic
Hardware Divide (2-12 Cycles)
Floating-Point Unit
 Optional single precision floating point unit
IEEE 754 compliant
Memory Protection
 Optional 8 region MPU with sub regions and background region
Bit Manipulation
 Integrated Bit Field Processing Instructions & Bus Level Bit Banding
Interrupts Non-maskable Interrupt (NMI) + 1 to 240 physical interrupts
Interrupt Priority Levels 8 to 256 priority levels
Wake-up Interrupt Controller
 Optional
Sleep Modes
 Integrated WFI and WFE Instructions and Sleep On Exit capability
Sleep & Deep Sleep Signals
Optional Retention Mode with Arm Power Management Kit
Debug
 Optional JTAG and Serial Wire Debug ports. Up to 8 Breakpoints and 4 Watchpoints
Trace Optional Instruction Trace (ETM), Data Trace (DWT), and Instrumentation Trace (ITM)

Compare all Cortex-M processors

Start designing now

Arm Flexible Access gives you quick and easy access to this IP, relevant tools and models, and valuable support. You can evaluate and design solutions before committing to production, and only pay when you’re ready to manufacture.

Learn more

Characteristics

Performance Efficiency: 3.42 CoreMark/MHz* and without FPU: 1.25 /1.52 /1.91 DMIPS/MHz**, with FPU: 1.27 /1.55 /1.95 DMIPS/MHz**

Arm Cortex-M4 Implementation Data***

180ULL
(7-track, typical 1.8v, 25°C)
 90LP
(7-track, typical 1.2v, 25°C)		 40LP
(9-track, typical 1.1v, 85°C)
Dynamic Power 151 µW/MHz 32.82 µW/MHz 12.26 µW/MHz
Floor plan Area 0.44 mm2 0.119 mm2 0.028 mm2

 * See product, compiler and compiler flags

 ** The first result abides by all of the “ground rules” laid out in the Dhrystone documentation, the second permits inlining of functions, not just the permitted C string libraries, while the third additionally permits simultaneous (”multi-file”) compilation. All are with the original (K&R) v2.1 of Dhrystone

 *** Base usable configuration includes DSP extensions, 1 IRQ + NMI, excludes ETM, MPU, FPU  and debug

Related IP

The Cortex-M4 processor is usually incorporated into a SoC using a broad range of Arm technology including System IP and Physical IP. It is fully supported by Arm development tools. Related IP includes:



Compatible IP
 Tools
 Software

Corstone Foundation IP

Socrates System Builder

Direct Memory Access Controller

CoreLink AHB Cache

Arm Development Studio

Arm Keil MDK Software Development Tool

Cortex-M Prototyping System

Fast Models

Cortex Microcontroller Software Interface Standard

Pelion IoT Platform

Mbed OS

Software Test Libraries

Trusted Firmware-M
Cortex-M comparison table
Feature  Cortex-M0 Cortex-M0+ Cortex-M1 Cortex-M23 Cortex-M3 Cortex-M4  Cortex-M33 Cortex-M35P  Cortex-M55
 Cortex-M7
Instruction Set Architecture  Armv6-M Armv6-M
 Armv6-M
 Armv8-M Baseline
 Armv7-M Armv7-M
 Armv8-M Mainline
 Armv8-M Mainline
 Armv8.1-M Mainline
Helium
 Armv7-M
Thumb, Thumb-2  Thumb, Thumb-2
 Thumb, Thumb-2
 Thumb, Thumb-2
 Thumb, Thumb-2
 Thumb, Thumb-2
 Thumb,
Thumb-2
 Thumb,
Thumb-2
 Thumb,
Thumb-2
 Thumb,
Thumb-2
DMIPS/MHz range*
 0.87-1.27  0.95-1.36  0.8
 0.98 1.25-1.89  1.25-1.95  1.5  1.5   1.6 2.14-3.23
CoreMark®/MHz*
 2.33 2.46  1.85
 2.64 3.34 3.42  4.02 4.02  4.2 5.01
Pipeline Stages
 3  2  3  2  3  3  3  3   4 6
Memory Protection Unit (MPU)  No  Yes (option) No  Yes (option)
(2 x) 		 Yes (option)  Yes (option)  Yes (option)
(2 x) 		 Yes (option)
(2 x) 		 Yes (option) (2 x)
 Yes (option)
Maximum MPU Regions  0  8  0  16  8  8  16  16  16
 16
Trace (ETM or MTB)  No  MTB (option)  No  MTB (option) or
ETMv3 (option) 		 ETMv3 (option)  ETMv3 (option)  MTB (option) and/or
ETMv4 (option) 		 MTB (option) and/or
ETMv4 (option)  		ETMv4 (option)
 ETMv4 (option)
Digital Signal Processing (DSP) extension
 No  No  No  No  No Yes  Yes (option) Yes (option)  Yes (option)
 Yes
Floating Point Hardware  No No  No  No  No Yes (scalar SP) Yes (scalar SP) Yes (scalar SP) Yes (scalar HP +
SP + DP) (vector
HP + SP)
 Yes (scalar SP + DP)
Systick Timer
 Yes (option)  Yes (option)  Yes (option)  Yes (2 x)  Yes Yes Yes (2 x) Yes (2 x) Yes (2 x)
 Yes
Built-in Caches  No No No  No No No No  Yes (option 2- 16kB Yes (option)
 Yes (option 4-64kB
 I-cache I-cache and D-cache
 I-cache, D-cache)
Tightly Coupled Memory  No  No  Yes  No  No  No  No  No  Yes
(option 0-16MB
I-TCM/D-TCM)
 Yes
(option 0-16MB
I-TCM/D-TCM)
TrustZone for Armv8-M
 No No No Yes (option)  No  No  Yes (option) Yes (option)  Yes (option)
 No
Coprocessor Interface  No  No  No  No  No  No  Yes (option)  Yes (option)  Yes (option)
No
Bus Protocol
 AHB Lite  AHB Lite, Fast I/O  AHB Lite  AHB5, Fast I/O  AHB Lite, APB   AHB Lite, APB  AHB5, APB AHB5, APB AXI5 (main bus), AHB
(peripheral bus,
TCM slave port and debug)
 AXI4, AHB Lite, APB, TCM
Wake-up Interrupt Controller Support
 Yes Yes  No  Yes  Yes  Yes  Yes  Yes  Yes
 Yes
Integrated Interrupt Controller (NVIC)
 Yes  Yes  Yes  Yes  Yes  Yes  Yes Yes  Yes  Yes
Maximum # External Interrupts
 32  32  32  240  240  240  480 480 480
 240
Hardware Divide  No No  No  Yes  Yes  Yes  Yes  Yes Yes
 Yes
Single Cycle Multiply
 Yes (option) Yes (option)  No  Yes  Yes  Yes  Yes  Yes  Yes
 Yes
CMSIS Support
 Yes  Yes  Yes  Yes  Yes  Yes  Yes  Yes  Yes
 Yes
Dual Core Lock-Step Support
 No No No Yes  No No Yes Yes  No
 Yes
Arm Custom Instructions
 No
 No
 No
 No
 No
 No
 Yes
 No
 Yes (available in 2021)
 No
Common Criteria certification No No  No  No  No  No  Yes  Yes  No No

*See individual Cortex-M product pages for further information.

SP = Single Precision

DP = Double Precision

HP = Half Precision
